DVB-T2机顶盒(DVB-T2)DV2108-T2高清数字电视机顶盒

DV2108-T2是一款高清数字电视机顶盒,全面兼容DVB-T2标准(MPEG2/h.264)。

* 全面兼容DVB-T2标准(MPEG2/h.264),满足NBTC标准
* 支持PAL,NTSC制式
* 支持多语言菜单:泰文、英文等
* 支持4:3,16:9荧屏宽高比,支持PAN&SCAN和信箱模式
* 7天电子节目指南,支持父母锁和喜爱频道,支持节目加锁、删除、移动
* 最大支持存储500个节目
* 支持环路高灵敏度
* 支持多音轨,多字幕
* 支持通过USB或OAD进行软件升级

General Features:
General Standards
DVB-T/T2 Compliant(MPEG2/H.264) S
According to standard requirement of NBTC S
Sensitive Tuner with Loop-Through S
Supported PAL, NTSC S
Variable aspect ratio(4:3,16:9) with PAN&SCAN vector or letter BOX option S
Output Resolution: 480i, 576p&576i, 720p&1080i 50Hz, 720p&1080i 60Hz, 1080p S
Storing Memory: 100 carriers, 500channels S
7days Electronic Program Guide(EPG) S
Favorite group and parental lock supported S
Supported programmer lock, delete, move S
Supported multi-language menu: Thai, English S
Multi-language audio S
Multi-language Subtitle output S
Supported Software upgrade by USB or OAD S
Supported USB 2.0 Interface S
Timer: S
  Supported 30 timers S
  Supported record event of EPG S
  Supported customized time to jump the designated program S
USB( FAT, FAT32, NTFS) S
  Supported Music Formats: MP3, AAC, M4A(.mp3, .m4a) S
  Supported Picture Formats: JPG, BMP, PNG (.jpg, .bmp, .png) S
  Supported Video Formats: MPEG-1, MPEG-2, MPEG-4, H.264, M-JPEG, AVI, MPG, MP4, TS, TRP, TP, MOV, MKV, VOB, DAT, XVID, M2TS S
  Supported External Subtitles: sub, srt, ssa, ass, smi, txt S
  Supported within hanging subtitles: txt S
USB PVR(FAT, FAT32, NTFS) S
Supported Recording and Playback TS files, supported Timeshift function S

Specifications:
Tuner Parameter Standards
Input Frequency: (UHF)470∽862MHz S
Input Level:  -85dBm ~ -20dBm S
Input Impendence: 75 S
Demodulation: QPSK/16QAM/64QAM / 256QAM S
Supported DVB-T/T2 Standard S

VIDEO Standards
Supported MPEG-1/2/4, AVC/H.264,VC-1 Video Decode S
Aspect Ratio: 4:3, 16:9 S
Supported PAL, NTSC Video Formats S
Supported HDMI high-definition Video Output S
AUDIO Standards
Supported MPEG-1LayerⅠ&Ⅱ,MP3, AAC-LC,HE-AAC,HE AACv2 Audio Decode S
Sampling Rate: 32KHz/44.1 KHz/48KHz S
Audio Output Impedance: Low S
Output Mode: Stereo, Left and Right S

PROCESSOR Standards
Flash Memory: 8MB S
DDRⅡ Memory: 64MB S
Demodulator: MSB1236C S

FRONT PANEL Standards
IR Receiver S
USB 2.0 Interface S
Keys S
Display 4 Digit, 7segment LED S
LED Indicator S
REAR PANEL Standards
RF IN S
RF OUT S
COAXIAL S
HDMI S
CVBS, Audio L&R S
DC IN S
OTHER Standards
Input Voltage: DC 5V/1.5A S
Power Consumption: 8W Max S
Ambient Operation Temperature: 0~40°C S
Product size: 145mm(length) X 94mm(width) X 30mm(height) S
ACCESSORIES Standards
Remote Control, Battery S
AV Cable S
Power Adapter S
User Manual S

  S:Standard features
  R:Customer requirement
