General | Standards |
DVB-T/T2 Compliant(MPEG2/H.264) | S |
According to standard requirement of NBTC | S |
Sensitive Tuner with Loop-Through | S |
Supported PAL, NTSC | S |
Variable aspect ratio(4:3,16:9) with PAN&SCAN vector or letter BOX option | S |
Output Resolution: 480i, 576p&576i, 720p&1080i 50Hz, 720p&1080i 60Hz, 1080p | S |
Storing Memory: 100 carriers, 500channels | S |
7days Electronic Program Guide(EPG) | S |
Favorite group and parental lock supported | S |
Supported programmer lock, delete, move | S |
Supported multi-language menu: Thai, English | S |
Multi-language audio | S |
Multi-language Subtitle output | S |
Supported Software upgrade by USB or OAD | S |
Supported USB 2.0 Interface | S |
Timer: | S |
Supported 30 timers | S |
Supported record event of EPG | S |
Supported customized time to jump the designated program | S |
USB( FAT, FAT32, NTFS) | S |
Supported Music Formats: MP3, AAC, M4A(.mp3, .m4a) | S |
Supported Picture Formats: JPG, BMP, PNG (.jpg, .bmp, .png) | S |
Supported Video Formats: MPEG-1, MPEG-2, MPEG-4, H.264, M-JPEG, AVI, MPG, MP4, TS, TRP, TP, MOV, MKV, VOB, DAT, XVID, M2TS | S |
Supported External Subtitles: sub, srt, ssa, ass, smi, txt | S |
Supported within hanging subtitles: txt | S |
USB PVR(FAT, FAT32, NTFS) | S |
Supported Recording and Playback TS files, supported Timeshift function | S |
Tuner Parameter | Standards |
Input Frequency: (UHF)470∽862MHz | S |
Input Level: -85dBm ~ -20dBm | S |
Input Impendence: 75 | S |
Demodulation: QPSK/16QAM/64QAM / 256QAM | S |
Supported DVB-T/T2 Standard | S |
VIDEO | Standards |
Supported MPEG-1/2/4, AVC/H.264,VC-1 Video Decode | S |
Aspect Ratio: 4:3, 16:9 | S |
Supported PAL, NTSC Video Formats | S |
Supported HDMI high-definition Video Output | S |
AUDIO | Standards |
Supported MPEG-1LayerⅠ&Ⅱ,MP3, AAC-LC,HE-AAC,HE AACv2 Audio Decode | S |
Sampling Rate: 32KHz/44.1 KHz/48KHz | S |
Audio Output Impedance: Low | S |
Output Mode: Stereo, Left and Right | S |
PROCESSOR | Standards |
Flash Memory: 8MB | S |
DDRⅡ Memory: 64MB | S |
Demodulator: MSB1236C | S |
Left SIDE PANEL | Standards |
RF IN | S |
RF OUT | S |
AV OUT | S |
DC IN | S |
RIGHT SIDE PANEL | Standards |
IR IN | S |
USB 2.0 Interface | S |
REAR PANEL | Standards |
HDMI | S |
OTHER | Standards |
Input Voltage: DC 5V/1.5A | S |
Power Consumption: 8W Max | S |
Ambient Operation Temperature: 0~40°C | S |
Product size: 154mm(length) X 74mm(width) X 24mm(height) | S |
ACCESSORIES | Standards |
Remote Control, Battery | S |
Power Adapter | S |
1 to 3 RCA Cable | |
User Manual | S |
IR extension cable | S |
S:Standard features
R:Customer requirement
